Batch And Coding Machine



TECHNICAL DETAIL OF  IMAJE INK JET PRINTER


Sr. No.

Feature

IMAJE 9020

1

Cabinet

Enclosure rated IP54. Most Compact in Size. Machine Weight – 18 Kg. Stand alone type. Flexible, can be easily moved from one production line to another.

Cabinet

2

Print Head

Simple molded print head which is highly reliable and easy to maintain. No adjustment needed.
No moving parts.

Print Head

3

Drop detection Electrode

It measures the charge of each drop being charged and gives the feed back, in case of a missed charging alternative drop is charged, Hence giving a consistent and good print quality

4

Head Maintenance

Head cleaning not required up to 21 days. No need of head removing while cleaning. Push fit type of cover.

5

Auto nozzle rinsing

Provided, Cleans the nozzle as well as the gutter automatically during startup and shut down both. Needs only 2 ml per cycle.

6

Jet dia

72µ in G head and 52µ in M head

7

Ink agronomics

Less dia of nozzles thus less ink consumption. High ink saving with M head ( 6-33% )

8

Bi jet Technology (Optional)

Can print up to 8 lines per head

9

Umbilical

Very flexible and MEK proof.

10

Head pressurization

Available, it pressurizes the print head with the compressed air thus avoiding any dust particles to enter the head.

11

Automatic nozzle unblocking feature

Available. Provides automatic nozzle cleaning without print head being opened.

12

Operator interface

QWERTY Key board integrated on to the machine which is, menu driven (Windows type) - very user friendly with one touch FUNCTION keys.

13

Display

Blue bright back lit display.
Big Icons. Very easy and comfortable to view from a distance.

14

"I" Button

Special feature which gives on line help to the operator incase of a fault

15

Consumable Level

Consumable level can be seen on the display.

16

Electronic

Latest, surface mounted device, multilayered tropicalised 2 main cards.
Highly reliable & suitable for our conditions.

17

Hydraulic circuit

Electronic compartment and hydraulic compartment are totally separated.

Simple hydraulic circuit needs only 1 phase power supply – no air supply needed.

Consumables only ink and solvent
Only Three filters used;
a) Air Filter, H.P. kit filter (to be changed every 2000 hrs of operation)

Not necessary to change ink circuit even if ink family is changed.

LOW RUNNING COST
AND LESS MAINTENANCE



Hydraulic circuit



Consumables can be changed without stopping the machine.

18

Ink wastage

No ink wastage

19

Auto jet speed control feature

Available. Computerized Jet speed control gives better print quality  even if pressure viscosity or temperature changes

20

Automatic visco control feature

Yes

21

Pressure control Feature

No adjustment, Computer takes care of in case temp and viscosity changes

22

Auto Break point adjustment

Not required as permanent jet speed control minimizes break point adjustment

23

Cannon with Piston closing at stop

Electro valve system closing hence no need for this.

24

Pring capabilities

2 line or 4 line with single print head-bijet technology available for better print quality & higher speeds (
Fonts: 5 x 5, 7 x 6,
9 x 7, 11 x 8, 14 x 12, 16 x 12,

Resolution – 2.8 dots/mm

Higher print speeds for multi line printing (Bi-jet)

Bowdlerization up to 9

25

Spares and consumables

Imaje offers low cost spares and consumables with guaranteed supplies.
Imaje ink is ketone based which is widely used in all sectors.
Imaje has obtained ISO14001 certification towards environmental safety.
